High Strength Lightweight Aluminium Concrete Formwork System
Our aluminum formwork is lightweight, high-strength, reusable and eco-friendly, enabling fast assembly and superior concrete forming for efficient construction. As both a manufacturer and a total solution provider, we offer professional engineering plans and one-stop support to meet your project needs.
- Product Introduction
Products Description
Our aluminum formwork is a high-performance, recyclable construction system manufactured from premium-grade 6061-T6 aluminum alloy. It is engineered to deliver exceptional structural stability, superior concrete forming quality, and significant on-site efficiency gains. The system is fully modular, lightweight yet robust, and designed for long-term repeated use. Environmentally compliant and fully recyclable, it meets the requirements of modern green building practices. As both a manufacturer and a comprehensive solution provider, we offer end-to-end support, from design and engineering to customization, production, and after-sales service, ensuring our clients receive a reliable, cost-effective solution tailored to their specific project needs.
Core Features & Advantages
Fast & Flexible Assembly: Modular design enables quick, tool-free assembly and disassembly, significantly reducing on-site labor time and costs.
High Structural Performance: High-strength aluminum alloy provides excellent load-bearing capacity and rigidity, ensuring structural safety during concrete pouring.
Superior Forming Quality: Smooth panel surface delivers high-quality, uniform concrete finishes with minimal defects, reducing post-construction finishing work.
Long Service Life: With a design reusability of over 150 cycles, the system offers a low total cost of ownership compared to traditional formwork solutions.
Lightweight & Safe: Low unit weight (18–25 kg/m²) reduces handling risks and improves construction site safety.
Environmentally Friendly: Fully recyclable material, minimizing construction waste and supporting sustainable building practices.
Versatile Application: Suitable for a wide range of projects, including residential buildings, commercial complexes, high-rise towers, and infrastructure works.
Technical Specifications
Material 6061-T6 Aluminum Alloy
Surface Treatment Anodized / Powder Coated
Standard Panel Sizes 400×2400 mm, 300×2400 mm (Custom sizes available)
Unit Weight 18–25 kg/m²
Design Reusability ≥ 150 cycles
Formwork Tolerance ±1.0 mm
Concrete Compatibility All common grades of concrete
Certifications ISO 9001, CE (Optional)
Customization OEM/ODM available (custom sizes, designs, and accessories)
System Components
The complete aluminum formwork system includes the following components to ensure full project compatibility:
●Wall panels, floor slabs, and beam forms
●Corner forms, adjustable props, and brackets
●Wedges, pins, and standard connection accessories
●Custom-designed parts based on project drawings
Quality & Compliance
All our aluminum formwork products are manufactured under a strict quality control system, complying with international standards. Each batch undergoes rigorous inspections, including material testing, dimensional checks, and load capacity tests, to ensure consistent quality and performance. We can provide relevant quality certificates and test reports upon request.
Engineering & Customization Services
●Our experienced engineering team provides professional construction planning, 3D formwork design, and technical recommendations based on your project drawings.
●We offer OEM and ODM services, including custom sizes, special shapes, and tailored solutions to meet unique project requirements.
●We provide detailed assembly drawings, installation manuals, and on-site technical guidance (if required)
Company Profile
TianTai is a professional manufacturer of aluminum formwork systems based in China. With advanced production facilities, a skilled workforce, and a strict quality management system, we are committed to delivering high-quality, reliable, and cost-effective formwork solutions to construction projects worldwide. We combine manufacturing expertise with comprehensive project support to become your trusted partner in construction efficiency.
