Wedge Lock Construction Scaffolding
The wedge lock scaffolding is a new load-bearing tool-type scaffolding developed by our company. Compared with other scaffolding systems, it significantly enhances workers' safety, project appearance, and construction efficiency. This product has obtained multiple national patents, and its comprehensive safety measures and flexibility have earned high praise from users. The main components of this scaffolding include vertical posts, horizontal bars, diagonal braces, adjustable bases, planks, adjustable wall connectors, and tripod brackets. All parts are lightweight—each weighs no more than 14kg, so one person can easily handle them, greatly improving work efficiency. Our product is made of Q355B steel (a high-strength low-alloy structural steel), and all components are hot-dip galvanized for corrosion resistance. This ensures a service life of 15+ years with zero post-use maintenance required. All performance test data fully comply with national standards.
- Product Introduction
Products Description
Our wedge lock scaffolding is a newly developed load-bearing tool-type scaffolding system, engineered and manufactured in-house. In comparison with conventional scaffolding solutions, it delivers a marked improvement in on-site worker safety, project finish quality and overall construction efficiency. This product has been awarded a number of national patents, and its integrated safety features and exceptional flexibility have won widespread acclaim from our clients.
The primary components of this scaffolding system include vertical standards, horizontal ledgers, diagonal braces, adjustable base jacks, scaffold planks, adjustable wall ties and tripod brackets. Every component is designed to be lightweight, with a single unit weighing no more than 14kg-enabling one-person handling and significantly boosting on-site operational efficiency.
Crafted from Q355B high-strength low-alloy structural steel, all components of our scaffolding undergo hot-dip galvanization for superior corrosion resistance. This robust construction guarantees a service life of over 15 years with zero post-installation maintenance required, and all performance test results fully comply with national industry standards.
Product Specification
|
Standard |
Specification(mm) |
Weight(kg) |
|
LG-36 |
Φ48.6*3600 |
14 |
|
LG-27 |
φ48.6*2700 |
10.2 |
|
LG-18 |
Φ48.6*1800 |
7 |
|
LG-09 |
Φ48.6*900 |
3.9 |
|
LG-045 |
Φ48.6*450 |
2.4 |
|
LG-08 |
Φ48.6*740 |
3.5 |
|
LG-09 |
Φ48.6*810 |
3.0 |
|
Ledger |
Specification(mm) |
Weight(kg) |
|
HG-18 |
Φ42*1800 |
4.3 |
|
HG-15 |
Φ42*1500 |
3.8 |
|
HG-12 |
Φ42*1200 |
3.0 |
|
HG-09 |
Φ42*900 |
2.4 |
|
HG-06 |
Φ42*600 |
1.7 |
|
HG-04 |
Φ42*400 |
1.2 |
|
LG-03 |
Φ42*300 |
1.0 |
|
HG-02 |
Φ42*200 |
0.8 |
|
Diagonal Brace |
Specification(mm) |
Weight(kg) |
|
XLG-18 |
w1800*H1800 |
4.0 |
|
XLG-15 |
w1500*H1350 |
3.5 |
|
XLG-12 |
w1200*H900 |
2.7 |
|
XLG-09 |
w900*H900 |
2.4 |
Advantages
Safety
The scaffolding assembled with wedge lock components boasts superior stability and safety performance. In addition, we provide a comprehensive lineup of complementary products that are perfectly matched to the scaffolding system, thereby completely eliminating safety risks during construction.
01
Efficiency
Assembly couldn't be easier-just one hammer is all you need. All components are engineered to be high-strength and lightweight, streamlining construction work and ramping up erection speed dramatically.
02
Flexibility
This scaffolding works seamlessly with irregular-shaped buildings-no site limitations, so it fits any complex construction site. It can be assembled into single-row, double-row, full-hall, skip, or cantilever scaffolds, covering all project needs. Plus, its clean, modern look means it doubles as a sharp construction enclosure too.
03
Cost-effectiveness
For this wedge-type scaffolding system, 1 ton of materials covers up to 100 sq.m of erected area-practical data shows this is twice the coverage of disc-lock scaffolding, and 2.5–3 times that of steel tube scaffolding.
04
Packing
Applications
Why Choose Us
With our rich experience we have unique skills and professional staff.Working closely with our clients to customize their exact needs has always been very rewarding for us.
Patented Design & Unmatched Safety
Patented design, national standard compliance, ultimate safety
Lightweigh
Lightweight , one-person assembly, high efficiency
High-Strength
355B steel + hot-dip galvanization, 15+ years lifespan, zero maintenance
Flexible
Flexible assembly, suitable for various construction scenarios
Technical Support
In the after-sales service,we provide technical services such as installation as well as commissioning and maintenance.
customization
One-stop professional customization & after-sales support
