Reusable Steel Green Formwork For Concrete Slab Construction Shoring System
The Green Formwork System is a practical and efficient formwork solution designed for concrete wall and slab construction. The system combines a durable Green Formwork Panel, Wall Filler Beam, and B35 Steel Prop to provide reliable support, accurate positioning, and efficient installation on construction sites. Designed with a focus on construction efficiency, reusability, durability, and cost control, Green Formwork is suitable for a wide range of residential, commercial, and infrastructure construction projects.
- Product Introduction
The Green Formwork System is a practical and efficient formwork solution designed for concrete wall and slab construction. The system combines a durable Green Formwork Panel, Wall Filler Beam, and B35 Steel Prop to provide reliable support, accurate positioning, and efficient installation on construction sites.
Designed with a focus on construction efficiency, reusability, durability, and cost control, Green Formwork is suitable for a wide range of residential, commercial, and infrastructure construction projects.
Product Specification
| Model | Dimension(mm) | Area(m2) | Unit Weight(kg) |
|
TT1121 |
1800X1200 |
2.16 |
45.0 |
|
TT189 |
1800X900 |
1.62 |
39.0 |
|
TT186 |
1800X600 |
1.08 |
31.4 |
|
TT1512 |
1500X1200 |
1.80 |
41.8 |
|
TT159 |
1500X900 |
1.35 |
33.3 |
|
TT156 |
1500X600 |
0.90 |
25.8 |
|
TT1212 |
1200X1200 |
1.44 |
34.0 |
|
TT129 |
1200X900 |
1.08 |
28.0 |
|
TT126 |
1200X600 |
0.72 |
23.0 |
|
TT99 |
900X900 |
0.81 |
19.0 |
|
TT66 |
600X600 |
0.36 |
14.3 |
SAFE
Stable formwork system with 6direction locking mechanism
Complete loadbearing capacity calculation available
No overhead lifting operations required
Keeps slab wellsupported during panel dismantling
SIMPLE & EFFICIENT
Only 4-worker team for erection, stripping and dismantling
Up to 500 sq.m working output per team per day
COST SAVING
Shorten overall construction cycle
Reduce total panel consumption
Cut down labor expenditure
Application
Packing
Our Service
Exhibition
